Gravity in 2001: A Space Odyssey

April 23, 2012 in Editorial

Aside from the classic problems of the Fridge Door Light and the Awkward Facebook Friend Request, there is another issue that keeps many of us awake at night. How do we exercise in Space? 2001: A Space Odyssey gave us an answer – simply have the astronauts run in a centrifuge that simulates gravity. About an hour into the movie we see one space jogger moving around quite comfortably. In fact, he appears to be moving with the same amount of ease as someone jogging on Earth, leading Centives to wonder: is the centrifuge spinning fast enough to generate a replacement for Earth’s gravity?

Using some creative math that we’ve outlined below, Centives figured out that the gravity that the astronauts felt in the centrifuge was just 4% of Earth’s gravity. This means that the gravity seen in the spacecraft is just a quarter of the gravity on our Earth’s very own moon – and the astronauts that visited the lunar surface had a fair amount of trouble getting around there. Our space protagonist shouldn’t be able to jog the way he does, unless those tight shorts conceal a considerable amount of added mass.

In fact, according to our estimates, in order to generate earth level gravity the centrifuge would have to spin slightly more than 12 times a minute, or five times as fast as it currently spins.

Another thing that the film makers seem to have glossed over is that since the man’s height is around one third the centrifuge’s radius, his feet are (relatively speaking), much further from the center than his head. Thus, his feet will be experiencing a much greater force, making it difficult for him to move normally.

If you’re more technically minded and want to know how we came to our conclusions, we started by figuring out the value of a few key variables.

First we took a look at the speed of the centrifuge. In the film, the character in question takes from 56:16 to 56:28 to run half the circumference of the centrifuge. We also know that he is, in fact, running in place as the wheel rotates around him. Thus, the angular velocity of the centrifuge can be estimated to be ∏ radians per 12 seconds.

To determine the radius of the centrifuge, we took the still frame above and measured the distance of the character and the radius of the centrifuge in pixels. The man is around 160 pixels and the centrifuge is 515 pixels. By estimating the man’s height to be 1.776m (average height of an American male), we estimated that the centrifuge had a radius of 5.73m.

We then plugged these values into the formulas outlined below. Click through the slideshow to see our steps. Hit the button on the lower left corner to expand it.
